Ozone Exposure Chamber DW5610
FYI is the best Ozone Aging Test Chamber supplier in the world, there is very few company manufacture Ozone Aging Test Chamber in the world. We offer good quality products with affordable price. The Ozone Aging Test Chamber DW5610 is of independent R&D, we provide not only good quality products, but also best after sales service.
Ozone Exposure Chamber DW5610
DW5610 Ozone Exposure Chamber can be used to determine the resistance of the color of textiles to ozone in the atmosphere at different temperatures with relative humidity.
Follows are features of the test chamber
- It can provide a constant temperature, humidity and ozone environment;
- Elegant appearance with large touch screen panel, real-time monitor, display and record ozone concentration, temperature and humidity data;
- Inner chamber made of high quality stainless steel;
- The specimen rack can accommodate specimens of various sizes;
- Rectangle glass window and illumination lamp enable users to observe.
Application
Application of Ozone Exposure Chamber
DW5610 Ozone Exposure Chamber can be used to determine the resistance of the color of textiles to ozone in the atmosphere at different temperatures with relative humidity.
Standards
Standards of Ozone Test Chamber
| ISO 105-G03 | AATCC 109 | GB/T 11039.3 |
|---|
Some standards might not be the full version; to read the full version for free, write an email to [email protected].
Please contact the administrator to get any violations removed.
Key specification
Key Specification of Ozone Test Chamber
| Control mode | PLC + Touch screen |
|---|---|
| Way to produce ozone | High-voltage corona discharge generator |
| Ozone concentration range | 0.1~500pphm |
| Ozone concentration monitor | Continuous real-time monitor |
| Ozone concentration accuracy | ±3% |
| Temperature range | RT~150℃ |
| Temperature accuracy | ±0.5℃ |
| Temperature uniformity | ±1℃ |
| Humidity range | 20~98%RH |
| Humidity uniformity | ±3%RH |
| Humidity accuracy | ±2.5%FS |
| Internal capacity | 500×500×600mm (L×W×H) |
| Power supply | AC220V, 50Hz |
| Dimension of machine | 1,200×1,050×1,750mm (L×W×H) |
| Net weight | 350kg |
