Carbon Fiber 3D Weaving Machine CFL3000
Carbon Fiber 3D Weaving Machine, also known as 3D carbon fiber loom , is used to weave thick carbon fabrics of GSM 800~2200. The carbon fiber fabric woven by our carbon fiber loom has a smooth surface and neatly arranged carbon fibers.
Carbon Fiber 3D Weaving Machine CFL3000
CFL3000 CF 3D WEAVING MACHINE is mainly used to weave thick CF fabrics with GSM 800~2200 up to 50mm in thickness. The equipment is composed by yarn rack, special weaving machine, etc.
The warp CF is provided from a warp yarn rack. The weft yarn is inserted by means of the auto-disc feeder. Finally, the finished fabric is wound up either inside the machine or with an external winder. Further processing made easy: high-quality CF fabrics.
CF is an abbreviation for carbon fiber.
For GSM 30~200:CFL1000
For GSM 200~600:CFL2000
Application
Application of Carbon Fiber 3D Weaving Machine
Carbon fiber is a high-strength and modulus high-temperature resistant fiber, which is a high-end variety of chemical fiber. It’s widely used in various fields. The importance of carbon fiber looms cannot be overstated.
Here is the fabric structure:
carbon fiber fabric structure
If you need more about carbon fiber loom and carbon fiber weaving equipment . please send email or contact with us directly.
Standards
Carbon Fiber 3D Weaving Machine Standards
Key specification
Key specification of Carbon Fiber 3D Weaving Machine
| Reed width (mm) | 600, 1000, 1200, 1500 |
|---|---|
| Max Speed | 60rpm |
| CF width | 6~8mm |
| CF fabric GSM | 800~2000, or specified |
| CF range | 3K, 6K, 12K |
| Noise | ≤65dB |
| Bobbin diameter | 200mm or as specified |
| Bobbin weight | 4~8kg or as specified |
| internal diameter of spool | 76/94mm or as specified |
| Length of spool | 280mm |
| No. of bobbin in creel | Max 960 or specified before place order |
