Drop Weight Impact Tester DW5351

Rated 0 out of 5
(be the first to review)

Drop Weight Impact Tester, also named Falling Weight Impact Tester or Drop Weight Tester. It is used to determine the impact toughness of all kinds of plastic pipe materials (such as the discharge pipe, the blowpipe, the gas pipe, the credit pipeline, such as PVC, PE, etc.). It is an ideal testing instrument for testing institution, production unit, building materials industry and scientific research unit.

Drop Weight Impact Tester DW5351

FYI- best Drop Weight Impact Tester Supplier of china with affordable price.

Drop Weight Impact Tester is suitable for all kinds of pipes (PVC -u feed pipe, drainage pipe, low pressure feed pipe, low pressure water pipe, core layer foam pipe, double-wall corrugated pipe, PE water pipe), the determination of the external impact resistance, can also be applied to hard plastic sheet.

We provide reasonable price and high quality Drop Weight Impact Tester.

All of testing instruments manufactured by FYI are well-known throughout China and more than 50 countries abroad for providing superior value and performance.

Follows are features of Drop Weight Impact Tester

  • LED display, long operating life;
  • Impact height can be adjustable within 50~2000mm;
  • Adopts imported servo motor control system, fast lifting device, high efficiency;
  • Automatically calibrate lifting height, calibration accuracy can be ±2mm;
  • Combined strikers, the striker weight can be assembled by different weights;
  • Pneumatic capture device for preventing second impact;
  • Combined vee-block, suitable for different specimen of different diameter.
  • Unique design of falling pipe and vent hole, which makes the air resistance of the hammer under the influence of air resistance is very small, and the hammer body has no friction with the falling wall, which can damage less than 2%;
  • .The sample adopts twin screw support, which is stable and rigid.

Application

Application of Drop Weight Impact Tester

Drop Weight Impact Tester is specially designed to determine the resistance to external blows of thermoplastic pipes and polymer test samples and components. It is suitable for PVC-U pipe, PVC-C pipe, PP pipe, PE pipe, communication pipeline, etc.

Drop Weight Impact Tester complies with ISO 4422, ISO 3127, BS EN 1411, BS EN 744 etc international and retailer standards.

If you need more information about Drop Weight Impact Testing Machine. Please contact with us.

Standards

Standards of Drop Weight Impact Tester

ISO 4422 ISO 3127 BS EN 1411 BS EN 744



Some standards might not be the full version; to read the full version for free, write an email to [email protected].
Please contact the administrator to get any violations removed.

Key specification

Key specification of Drop Weight Impact Tester

Striker weight 0.250~15.00kg (increment: 0.100kg and 0.250kg), selectable
Striker radius 12.5mm, 50mm, can be customized
Specimen diameter 50-2000mm±2mm
Nose of strikers 10-630mm
Power supply 220V, 50Hz
Max. striker lifting speed 12m/min
Dimensions 1100×570×3710mm (L×W×H)
Weight approx. 260kg
