ICI Pilling and Snagging Tester YG511 series

Rated 0 out of 5
(be the first to review)

ICI Pilling and Snagging Tester, also named ICI Pilling Box or Pilling Machine which is used to determine the surface fuzzes and pilling properties of both woven and knitted materials.

ICI Pilling and Snagging Tester YG511 Series

ICI Pilling And Snagging Tester can be used to test both woven and knitted materials. It complies in full with the requirements of EN ISO 12945-1 ‘Textiles – Determination of fabric propensity to surface fuzzing and to pilling – Part 1: Pilling Box Method.’ This standard supersedes BS 5811, which is now withdrawn. In addition to Orbitor fulfil the requirements of GB/T4802.3-1997.

Follows are features of the pilling tester:

  • Electronic counter can record accumulated number of test cycles automatically, also easy to reset the counter;
  • Simplified designing, more convenient to operate, and easy to maintain;
  • Synchronous speed motor drives the test boxes, ensuring constant speed of rotation.

Application

Application of ICI Pilling and Snagging Tester

ICI pilling tester is mainly used for pilling of shuttle and knitted fabrics caused by friction without pressure. when sample pasted on the rubber hose, prevent to the test cabinet and make test box rotates at a certain speed, is the sample and the lining and mutual free friction, after a specified time, remove the specimen, contrast diagram evaluation sample card friction resistance level.

The unit consists of frame, drive system, pilling boxes, electronic control cabinet, and control panel.(see figure 1).

The Pilling boxes are secured in box rack, two ends of box rack are connected to frame and electronic control cabinet respectively. The Frame and control cabinet are joined as a whole.

If you want to know more detailed about ICI Pilling Box, please contact with us.

Standards

ICI Pilling and Snagging Tester standards

EN ISO 12945-1 BS 5811



Some standards might not be the full version; to read the full version for free, write an email to [email protected].
Please contact the administrator to get any violations removed.

Key specification

Key specification of ICI Pilling and Snagging Tester

Pilling drum no. 2(YG511-II)
4 (YG511-IV)
6(YG511-VI)
Drum volume 235×235×235mm (L×W×H)
Rotational speed 60 r/min
Counter 1~99,999, LED display
Specimen tube size Φ32×140mm
Specimen tube weight 52.5g
Power supply AC220V, 50Hz
Weight 60kg (YG511-II)
90kg (YG511-IV)
110kg (YG511-VI)
