Rotational Viscometer NDJ/SNB Series

Rated 0 out of 5
(be the first to review)

NDJ/SNB Series Rotational Viscometer is used to measure the viscosity property of various fluids or semi-fluids. It can also measure the dynamic viscosity or structural viscosity of mineral oil, lubricating oil, adhesives, paint, dyestuff and ink.

Rotational Viscometer NDJ/SNB Series

NDJ/SNB Series Rotational Viscometer is used to measure the viscosity property of various fluids or semi-fluids. It can also measure the dynamic viscosity or structural viscosity of mineral oil, lubricating oil, adhesives, paint, dyestuff and ink.

Follows are features of rotational viscometer

  • Direct readout of all measurement parameters on an illuminated Liquid Crystal Display;
  • Spindles made of AISI 304;
  • Auto range function to determine the maximum viscosity with spindle/speed combination;
  • Ultra-sensitive front keyboard that allows easy inquiry of all parameters;
  • “ERROR” message in the screen with sound alarm when the viscosity of the test materials exceeds the full scale of the selected combination (SP/RPM);
  • Sound alarm if the equipment is working at under 20% of the selected full scale;
  • Safety protection against sudden rises in the power supply;
  • Direct reading in cP (mPa.s), portable and easy to operate;
  • NDJ-5S/8S: The viscometer is equipped with many pre-set speeds, from 0.3 to 60 rpm;

Application

Application of Rotational Viscometer

NDJ/SNB Series Rotational Viscometer is used to measure the viscosity property of various fluids or semi-fluids. It can also measure the dynamic viscosity or structural viscosity of mineral oil, lubricating oil, adhesives, paint, dyestuff and ink.

If you need more information about rotational viscometer, please contact us.

Standards

 Standards Of Rotational Viscometer

STANDARDS  ISO 2555  ISO 1652

Note: this rotational viscometer can conform to but not limit to the standards above, for more standards conformance, please contact us.

Some standards might not be the full version; to read the full version for free, write an email to [email protected].
Please contact the administrator to get any violations removed.

Key specification

Key Specification OfRotational Viscometer

Model NDJ-5S NDJ-8S SNB-1 SNB-2 SNB-3
Measure range (cP) 10-100K 10-2,000K 10-600K 10-6,000K 100-80,000K
Accuracy ±1% of full scale
Repeatability 0.5%
Speed (rpm) 6, 12, 30, 60 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 1-60 0.1-100 0.1-100
Temp range (0-100.0)℃ (optional) (0-100.0)℃
Temp resolution / 0.1
Temp accuracy / ±0.1
Temp probe RTD (optional) RTD
Output RS232
