Sole Abrasion Resistance Tester DW9300GB

Rated 0 out of 5
(be the first to review)

Sole Abrasion Resistance Tester, also called Whole Shoe Abrasion Tester or GB Abrasion Testing Machine, which is used to test the resistance of whole shoe soles and unit soles (sheets) to abrasion by the test method specified in GB/T 3903.2. It is mainly used in rubber sole, TPR sole, PU sole and plastic sole, shoe or specimens of wear Resistance test.

Category:

Sole Abrasion Resistance Tester DW9300GB

Sole abrasion resistance tester is used to test the rubbing resistance property of sole, rubber, PBR, polyurethane and other reference materials. The rotating grinding wheel presses on the specimen vertically with specified load and speed for a certain period of time. After rubbing is completed, measure the length of grinding crack.

Follows are features of the abrasion resistance tester:

  • The position of grinding wheel can be adjusted by hand wheels;
  • The grinding wheel rotates clockwise and smoothly;
  • Test load can be adjusted by adding or reducing the weights on the balance.

For more information,you can also visit www.fyichina.com.cn

Application

Application of sole abrasion resistance tester

Sole abrasion resistance tester is suitable for the abrasion resistance test of whole shoe soles and unit soles (sheets). The abrasion resistance of soles can be obtained by using the tester to grind the flat surface of outsole with rotating steel wheel for a specified time, and then measure the length of grinding crack.

Sole abrasion resistance tester complies with GB/T 3903.2.

If you need more information about sole abrasion resistance tester, please contact us.

Standards

Standards of sole abrasion resistance tester

GB/T 3903.2



Some standards might not be the full version; to read the full version for free, write an email to [email protected].
Please contact the administrator to get any violations removed.

Key specification

Key specification of sole abrasion resistance tester

Grinding wheel size Ф(20±0.1)mm×(4±0.1)mm
Rotation speed of grinding wheel 191±5rpm (10~300±5rpm, adjustable)
Test load 500g, adjustable
Timer range 0~9999h59min59s, LCD display
Power supply AC 220V 50Hz
Package dimensions 750×660×780mm (L×W×H)
Net/Gross weight 75/88kg
