Bench UV Light Accelerated Weathering Tester DW1412

Rated 0 out of 5
(be the first to review)

Bench UV Light Accelerated Weathering Tester, also named UV Light Accelerated Weathering Tester, or Accelerated UV Weathering Testing Machine. FYI is one of the best UV accelerated weathering tester manufacturers in the world, offering high quality machines with affordable price.

Bench UV Light Accelerated Weathering Tester DW1412

FYI- best Bench UV Light Accelerated Weathering Tester manufacturer and supplier of china, we offer high quality UV accelerated weathering tester and devoting to offering cost effective testing solutions and equipments for various industrial applications.



Features of bench UV light accelerated weathering testing

  • Touch screen and user-friendly operation interface allowing handler to set test parameters and monitoring all test process easily;
  • Professional UV lamps;
  • Full stainless steel inner working room with sandwich design, never getting rusty and leakage; also prevent water vapor coming from working room from entering electrical box and damaging electron components;
  • Water-level switch will alarm and stop running automatically when below low water level;



Application

Application of Bench UV Light Accelerated Weathering Tester

Bench UV Light Accelerated Weathering Tester is used to determine results of material weathering.

The product adopts fluorescent uv lamp as the light source, simulates the ultraviolet radiation and condensation in natural sunlight, and accelerates the weathering test of materials to obtain the results of material weathering.

It is an economic and easy-to-use machine which can meet some customer’s requirements. It is equipped with 3pcs 20W UV lamps as light sources. Operator can set the total illumination time, temperature, spray time, etc, to simulate the natural environment which cause the damaged factor to samples. The chamber can isolate 18pcs standard panels (150×70mm).

Samples are installed a column form rotating sample rack. During the test, the sample rack rotates uniformly and ensure every sample get the same irradiance energy, increase the comparability and repeatability of testing results.

Full stainless steel inner working room with sandwich design, never getting rusty and leakage; also prevent water vapor coming from working room from entering electrical box and damaging electron components

Bench UV Light Accelerated Weathering Tester complies with Non Standard international and retailer standards.

If you need more information about Bench UV Light Accelerated Weathering Machine. Please contact with us

Standards

Standards of Bench UV Light Accelerated Weathering Tester

Key specification

Key Specification of Bench UV Light Accelerated Weathering Tester

Temperature range of working room 1~9,999h, settable
Test time 1~9,999h, settable
Spray time 1~9,999min, settable
Spray interval time 1~9,999min, settable
Lamp type UV-A lamp (313nm) or UV-B lamp (340nm)
Rated lamp life 1600h
Lamp power 20W×3
Spray water Approx. 2L/min
Number of test panels 18pcs, 150×70mm for each
Power supply AC220V 50Hz, 1200W
Dimensions 930×450×630mm(L×D×H)
Weight 63kg
