Fiber Bundle Strength Tester YG011

Rated 0 out of 5
(be the first to review)

Fiber Bundle Strength Tester, also named STELOMETER. FYI is one of the best fibre bundle strength tester suppliers in the world, we offer good quality products with affordable price. The fiber bundle strength tester is of special design, R&D, we provide not only good quality products, but also best after sales service.

Fiber Bundle Strength Tester YG011

We provide reasonable price and high quality Fiber Bundle Strength Tester. All of testing instruments manufactured by FYI factory are well-known throughout China and more than 50 countries abroad for providing superior value and performance.

This fibre bundle strength tester is used in conjunction with a precision balance to provide precise, repeatable determinations of both tenacity and elongation at 1/8″ gage spacing and of tenacity at zero gage spacing.

Follows are features of fiber bundle strength tester(stelometer)

  • Calibrate each stelometer by force measuring and elongation devices that are special designed by our company only, ensure pointer indications (force value and elongation) are match to real value and keep test result stable and high accuracy;
  • Special designed table clamps and pressley clamp can hold fiber tufts effectively, and avoid slipping or affect test as hold tight;
  • Read test values of breaking strength and elongation directly from two scales after finishing test;
  • After fiber tufts breaks, there is no malfunction mistakes;
  • Test result with high accuracy and with good correlation with yarn strength.

Application

Application of Fiber Bundle Strength Tester

Fiber Bundle Strength Tester is an instrument which breaks a flat bundle of textile fiber and indicates on graduated scales, the force required to break the bundle and the elongation of the fiber at moment of breaking. Breaking force may be converted to breaking strength (tenacity) by means of simple calculation when the length of the fibers in the bundle and the weight of the fibers are known.

Fibre Bundle Strength Tester complies with ISO 3060 etc international and retailer standards.

If you need more information about Fiber Bundle Strength Tester/Stelometer Tester. Please contact with us

Standards

Standards of Fiber Bundle Strength Tester

ISO 3060 ASTM D1445/2524



Some standards might not be the full version; to read the full version for free, write an email to [email protected].
Please contact the administrator to get any violations removed.

Key specification

Key Specification ofFiber Bundle Strength Tester

Thickness of separator 3.2mm
Elongation range 0~50% at 1/8’’ gage spacing
Loading speed 10N/S (adjustable)
Tenacity Correction Coefficient(Approxi) 0.9~1.1
Elongation Correction Coefficient 0.8
Pressley clamp Thickness 11.8mm
Spacer 3.2mm (1/8’’)
Dimensions 320×390×160mm
Weight 10kg
