PNEUMATIC HEAVY DUTY PADDER MU505 SERIES

Rated 0 out of 5
(be the first to review)

Pneumatic Heavy Duty Padder which also named pneumatic heavy duty padder, lab padding mangle, or lab padder.FYI is one of the leading suppliers and manufactures of heavy duty padder which supply best solution for lab padder.

 PNEUMATIC HEAVY DUTY PADDER

MU505 Series Pneumatic Heavy Duty Padder is used as the dyeing and finishing padding mangle.

Nowadays customer requires not only the precise color but also the good hand-feeling of the finished goods. With this device, you could get the high repeatability sample by simulating the real production environment; with it, you also can develop the value added, add functions of fabrics like fireproofing, dust-resistant, oil-resistant, water-repellent, breathable etc., to develop new business, new benefits and improve competitiveness of the products.

Follows are features of heavy duty padder:

  • Roller made of imported rubber with NBR coating, acid/alkali-resistant, corrosion-resistant, good elasticity and long service life;
  • Two air cylinders control each end of roller to keep uniform pressure;
  • Pressure regulating valves to control the roller pressure;
  • Cloth speed controlled by frequency conversion within 0~10m/min;
  • Mirror stainless steel surface, easy to clean and good appearance;
  • Be equipped with air gun and sprinkler for cleaning padder expediently;
  • Compressed air supply required;



APPLICATION

Application of Heavy Duty Padder

MU505 SERIES PNEUMATIC HEAVY DUTY PADDER is used as the dyeing and finishing padding mangle.

If you need more information about heavy duty padder. Please contact with us.

Standards

Heavy Duty Padder Standard



Key specification

Key specification of Heavy Duty Padder

Model MU505A MU505B
Type Vertical Horizontal
Dimensions (L*W*H) 920*620*1,200mm 900*600*1,050mm
Roller width 450mm
Roller diameter φ130mm
Max. air pressure 0.5MPa
Retained dyestuff ratio 25%~110%
Speed 0~10m/min (variable frequency adjustable)
Power supply AC220V, 50Hz, 1 phase
