Textile Machine Bid for Sylhet Textile Engineering College

Tenderer

Sylhet Textile Engineering College, as a university still under construction, recently issued a tender to purchase some textile equipment. As a company that has been deeply involved in the bidding field for many years, Hefei Fanyuan naturally participated in this tender. Below are some specific information and parameters of the tender.

Request for the bids

• Tender ID: 1099739; Goods (NCT)
• APP ID: 213131; Region: Dhaka
• Reference Number: 24.02.0000.073.07.035.22-283
• Package Title: Procurement of Knitting Department, Clothing Engineering Department, Fashion and Design Department, Testing and Quality Control Department, Mechanical Engineering and Workshop and Electrical Laboratory Equipment for Textile Engineering College, Sylhet.
• Organization: Department of Textiles
• Procuring Entity: Sylhet Textile Engineering College, Sylhet
• Procurement Method: Open Tender Method (OTM)
• IFT Release Date: 2025-04-29 10:00:00
• Document Last Sale Date: 2025-05-20 12:30:00
• End/Start Date: 2025-05-20 15:00:00
• Brief Description of Package: Procurement of Knitting Department, Clothing Engineering Department, Fashion & Design Department, Testing & Quality Control Department, Mechanical Engineering & Workshop and Electrical Laboratory Equipment for Sylhet Textile Engineering College.
• Bid Document Price: Tk 4000; Bid Security: BDT 1250000
• Official Cost Estimate (Forecast):

As the document price is Tk 4000, the estimated cost should be more than BDT 20 million.

Bid Security can be up to 3% of the Official Cost Estimate. Therefore, the estimated cost will be more than 41666666 Taka.

Bid security is usually 1% higher than the official cost estimate. Therefore, the estimated cost should be less than 125000000 BDT.

Therefore, the official cost estimate should be 125000000 BDT. 41666666 ~ 125000000.

Machines for Sylhet Textile Engineering College

Padding Mangle (lab type)

For resin processing and to provide total solutions on incommensurable colorant pick-up rate during the press & dyeing process held in lab and in factory.

Feature

• Floor model – to save the trouble from preparing workstations.
• One pair of vertical type NBR roller, length:450mm, diameter:125mm.
• The padding roller pressure can be adjusted right and left independently to ensure precise measurement.
• 70 hardness degree and 6kg/cm2 of durability.
• The speed of roller is 10 R.P.M.
• Safe emergency system: Emergency touch switch and knee hidden.
• Pressure board signals the motor to stop automatically to guarantee the safety of the users.

Specification:

• System: vertical type
• With one pair of padding rollers made of N.B.R rubber of 70°shore hardness.
• Roller dia 125mm length 450mm.
• 2 pressure gauges accuracy 0.1kg/cm.
• 2 pressure regulators (“WIKE” made in Germany)
• Safety devices include fabric feeder safety rod, knee pedal and emergency button.
• One mobile chemical trough.

Sample jet dyeing machine (Lab type):

Laboratory Dyeing, machine for high temperature and high pressure sample dyeing of fabrics in rope form.

Feature

• Adjustable four-shape nozzle sprays dyeing liquid widely and makes it  great for dyeing surface – sensitive material since it circulates with spreading textiles.
• Nozzle cleaning have to be convenient.
• Effective for high quality dyeing of textiles, such as cotton, wool, knit, complex and others.
• It have to be widely applied with spraying 50g/m~600g/m.
• Programmable Controller

Specification

Winch Dyeing Machine (lab type):

Specification

• Volume: 1.55 m2,  Roller Speed: 5-60 r/min,
• Transmission electrical machine: 1.1 Kw
• Produce with cloth machinery: 0.75 Kw
• Steam Pressure: 0.4~0.8 Mpa
• Area required (aprx): 1600X3200X1750
• Weight: 800 kg

Hank Dyeing Machine:

Hank Dyeing for chemical fiber, polyester staple fiber or cotton etc.

Feature

The grooves which support the sticks with different distances between sticks

Reversible Impellor to ensure even flow of liquor.

Adjustable flow rate

Automatic temperature control panel

Should have option to inter coupling two or more cabinets of same size for dyeing large batch of hank of same shade

Specification

No of hanks: 20 Nos

Weight of yarn: Wool: 30, Acrylic: 20

Circular Motor: 1 Kw

Floor: 1,  Liquor: 0.4 m2

Capacity :5-25 kg

Diameter of main tank : Φ430

Designed Pressure : 0.44Mpa

Max work Pressure :0.44Mpa

Designed Temperature :98ºC

Max work Temperature :95ºC

Cooling water Temperature :5ºC-10ºC

Power :4.00-7.5KW

Hydro extractor

Hydro extractor for fabric, bobbins, hanks with

Features

Internal basket diameter 400mm

cover with safety device rotation speed 1450 tours/min. or with inverter.

Basket Dimension (DxHxV): 400x300x34

Machine Dimension (LxDxH): 610x515x760)

Body must be stainless steel

Specification

Load capacity: 6 Kg (minimum)     Power:  1.10 (Kw),

Volume : 34 Liters (minimum)

Tumble Dryer

This air-vented tumble dryer is used to simulate domestic laundering conditions and is designed to reduce machine and operator variables to the absolute minimum.

Specification

Exhaust Temperature: Maximum 80˚C

Rotational Speed: 56 rpm

Capacity: 5kg,

Volume: 95 L

Power: Single phase 220/230V 50Hz/60Hz

Standards

EN ISO 6330:2012,  Marks & Spencer P1A,  Next 7, 7a, 7b, 9, 10, 11, 12, 34 and 36a

Automatic Lab Jigger

Specification

Fabric Width   : Max. 400mm.

Speed  :  Up to 6 meters/min.

Length of fabric : Up to 20mm thickness of fabric when wound on one of the rolls.  Volume to dteliquor  :  1.8 Ltr.

Electric supply  : 220V AC, Single Phase, 10 Amps.

Floor Space  : 1.5 Mtr.  X 1 Mtr.

Heating of dye liquor : Through electric heater.  Max. Temp.  98 deg.

Sample dyeing Machine

Sample dyeing machine for laboratory scale equipped with programmable microprocessor controller applicable in the normal temp. or high temp. Dyeing, energy saving and environmental protection, it provides you convenient, low liquid ratio, No wrinkle on the fabrics, Intelligent Chemical lid, Suitable for powder and liquid chemical adding. In multi-purpose laboratory dyer.

Specification

a.   Heating System: Electric bath filled with Fesant

b.   Max. Heating power: 4.5KW (MAX.)

c.   Temperature range:   20©c – 135©c

d.   Dyeing Capacity:

      Beaker size:                  150- 200 cc

      No. of beaker –              24 pot

e.   Rotation speed:   60 rpm (max.)

f.    Program step:   Automatic

g.   Voltage:     220V Single Phase.

h.   Frequency:   50/60 Hz

With Standard Spares.

Dimensions : Width:  670mm, Depth:  720 mm, Height:  750 mm
