Yarn Sample Winder Y108D Series

5.0 (1 review)

Yarn Color Chart Winder, also named Yarn Card Winder, Colored Yarn Sample Winder or Yarn Winder Machine. FYI is one of the leading manufacturers and suppliers of yarn winder, devoting to offering cost effective testing solutions and equipments for various industrial applications.

Yarn Sample Winder Y108D Series

Y108D Series Electronic Yarn Sample Winder is used for winding yarn sample cards. On a hard paperboard with maximum length of 290mm and maximum width of 60mm, up to 20 yarns can be wound simultaneously according to pre-determined winding speed, width, layer and density. Suitable for sample card, UV resistance measurement, sample adjusting, colorimeter testing, cleanness degree and winding color card.

Follows are features of Yarn Color Chart Winder

  • Microcomputer control, LED display;
  • Digital setting of winding speed, winding width, windinglayerand winding densitythrough control panel to ensure the uniformity of the yarn sample cards;
  • Fitted with stepper motor as power winding, adjustable tensioner to adjust yarn tension as needed;
  • Speciallydesigned holder, easy to operate and endurable.



Application

Application of Yarn Sample Winder

Yarn Sample Winder is use to produces yarn sample cards. Suitable for sample card, UV resistance measurement, sample adjusting, colorimeter testing, cleanness degree and winding color card.



If you need more information about Yarn Winder Machine. Please contact with us

Standards

Standards of Yarn Sample Winder

Key specification

Key Specification of Yarn Sample Winder

Model No. Y108D-1,Y108D-20
Working position Y108D-1:   1

Y108D-20:   20

Winding speed 100~900 r/min (settable)
Winding width 5~50 mm (settable)
Winding layer 1~99 layer (settable)
Winding density Stroke per step 0.01~0.99 mm (settable)
Power supply AC220V, 50Hz
Main machine dimensions (L*W*H) Y108D-1: 500*460*390 mm

Y108D-20: 850*400*420 mm

Reel rack dimensions (L*W*H) Y108D-1:  /

Y108D-20: 530×530×550 mm
