Lab Machine Bid for Madaripur Textile Engineering Institute

Tenderer

Madaripur Textile Engineering Institute was recognized by Technical Education Board in 2010. It first opened for business on July 13, 2010. By giving students access to contemporary technologies and work-based learning opportunities, the university hopes to foster a self-employment industry. A four-year diploma in textile engineering is offered by Madaripur Textile Engineering Institute. It has all the necessary technological components to give students the most academic and applied education possible. The Madaripur Textile Engineering Institute provides the equipment and supplies needed to give students the greatest hands-on training possible, as well as knowledgeable instructors who can assist students with their theoretical issues in their respective professions. An outstanding example of an institution is the Allover Madaripur Textile Engineering Institute, or M.T.E.I.

Information for Tenderer/Consultant

Bidder Qualifications: Bangladesh nationals must possess the following:

1. Valid National Identification Number (NID)

2. Valid business license

3. Valid Taxpayer Identification Number (TIN) and latest tax return certificate

4. Valid Bank Identification Number (BIN)

5. At least five years of general experience in the public sector.

6. At least three years of specific experience in the supply of textile machinery to the public sector.

Brief Description of Procured Goods and Related Machinery and Equipment: The scope of procurement covers: Departments of Garment Manufacturing, Apparel Engineering, Fashion and Design Services, Wet Process Engineering, Mechanical Engineering, and Workshop Mechanics of Madaripur Textile Engineering College.

Evaluation Type: By Lot

Document Available: By Package

Document Fee: By Package

Bidding/Proposal Documents: Price (4,000 Bangladeshi Taka):

Payment Method: Bank Payment

Bidding/Proposal Deposit Valid Until: November 12, 2025

Bidding/Proposal Valid Until: October 15, 2025

Knitting machines in the tender

Dial Linking Machine

• Diameter of Dial : 12-14
• Power Required :1/8-1 HP
• Pulley Revolution: 350 RPM
• Power :220V
• Frequency :50/60Hz
• Machine should be set with standard table & frame.
• Warranty : To be mentioned by the bidder
• Required Documents: ISO certificate, Catalog, Manufacture Authorization Letter

Circular knitting machine (Single Jersey)

1. Anti-static aluminum tub creel

2. Lycra provision wheel on the yarn guide

3. positive feeder

4. oil lubricator

5. Top dust cleaner with 4pcs fan

6. Middle cleaning fan with air flusher

7. Electronic control panel

8. Transistor inverter: 5-7.5 HP/440V Automatic counter

9. mechanical/automatic take up device

10. Needle detector :

11. Inserted Cylinder

12. Graz Beckert Needle

13. Cam/Cylinder

14. Cam Arrangement: 6 Cam/ Feeder.

15. Indicator alert lamp system

16. Tool Box with hand tool: 1 Box

17. Operation manual for machine, oil lubricator, inverter

Spare for Each Machine:

Top Needle 100 pcs.

Bottom Needle 100 pcs

Spare Cam 1 pc each type

Positive feeder :1 pc.

Fuse:3pcs.

Warranty : To be mentioned by the bidder

Rib Knitting Machine

Gauge: 18-32 Gauge

Feature :

Adapt oil-bath for the driver gear so as to reaches the smoothest gear transmission and the lightest noise from machine. The unique design for Cam & Cylinder so that machine produces fabrics with smooth and soft. Machines are equipped with conductor to protect all electric components against the unsteady voltage supply. Drive System: Applies 3 transmission shafts which move simultaneously, Knitting Cylinder : Applies specially steel material for sturdiness. Cam Design: All cams incorporate imported alloy materials and treatment by CNC for smooth operation at high R.P.M

Specification:

Cylinder Diameter: 12-16″

Machines gauge: 18-32G

No of Feeders: 48 feeder or More

1. Anti-static aluminum tub creel

2. Lycra provision wheel on the yarn guide

3. positive feeder

4. oil lubricator

5. Top dust cleaner with 4pcs fan

6. Middle cleaning fan with air flusher

7. Electronic control panel

8. Transistor inverter: 5-7.5 HP/440V Automatic counter

9. Needle detector :

10. Inserted Cylinder

11. Graz Beckert Needle

12. Cam/Cylinder

13. Cam Arrangement: 6 Cam/ Feeder.

14. Indicator alert lamp system

15. Tool Box with hand tool: 1 Box

16. Operation manual for machine, oil lubricator, inverter

17. CE/ ISO Certificate.

Spare for Each Machine:

Top Needle 100 pcs.

Bottom Needle 100 pcs

Spare Cam 1 pc each type

Positive feeder: 1 pc. Fuse :3pcs.

Circular socks Machine

Cylinder Diameter: 3” / 3 1/2” / 3 3/4” / 4” / 41/ 2” / 5”

Needle Range: 56-220N

Running Speed: Max about 280-380 R.P.M

Drive Motor Power: 0.8-1.0KW

Fan Motor: 0.75KW

Control Box: 0.8KW

Control: Fully Computerized

Crochet knitting Machine

To product lace tapes of kinds of high-grade garment, shop cap, bedding & curtain

Specification:

Gauge :10/12/14/15/16/18/20

Total Working Width : 20-30”

Number of weft rows: 3 (Minimum)

lace width : 70-300 mm

Speed : 150 rpm ( Minimum)

Motor horse power : 1.5 HP,

standard spares. Required

Documents : Catalog,

Manufacture Authorization letter,

Warp Knitting Machine

Technical Specification:

Operating Width: 60”

Operating System: PLC & Touch Screen

Gauge Per Inch: 12-18 G

Weft Bars: 4 bars

Motor: 2 HP

Speed: 1400 RPM

Power: 2.2Kw, 440v, 3Phase, 50Hz.

Production: 27 meters/Line/ Hour

Normal Attachment: Inverter, finished product collecting roller, Creel Beam holder.

Yarn Feeding Option: By standard Needle loom beam and warping machine.

Additional requirements to run the machine.

Additional Attachments: 4 pcs Beam

Dyeing machines in the tender

Padding Mangle (lab type)

For resin processing and to provide total solutions on incommensurable colorant pick-up rate during the press & dyeing process held in lab and in factory.

Feature:

– Floor model to save the trouble from preparing workstations.

– One pair of vertical type NBR roller, length:450mm, diameter:125mm.

– The padding roller pressure can be adjusted right and left independently to

ensure precise measurement.

– 70 hardness degree and 6kg/cm2 of durability

– The speed of roller is 10 R.P.M.

– Safe emergency system: Emergency touch switch and knee hidden

Pressure board signals the motor to stop automatically to guarantee the safety of the users.

Specification:

System: vertical type

With one pair of padding rollers made of N.B.R rubber of 70°shore hardness.

Roller dia 125mm length 450mm.

2 pressure gauges accuracy 0.1kg/cm.

2 pressure regulators (WIKE made in Germany)

Safety devices include fabric feeder safety rod, knee pedal and emergency button.

One mobile chemical trough.

Sample jet dyeing machine (Lab type)

Laboratory Dyeing, machine for high temperature and high pressure sample dyeing of fabrics in rope form.

Feature:

Adjustable four-shape nozzle sprays dyeing liquid widely and makes it great for dyeing surface sensitive material since it circulates with spreading textiles.

Nozzle cleaning have to be convenient.

Effective for high quality dyeing of textiles, such as cotton, wool, knit, complex and others.

It have to be widely applied with spraying 50g/m~600g/m.

Programmable Controller

Specification:

Capacity upto: 3-5 Kg.

Pressure (Minimum) upto : 5Kg./cm2

Temperature (Max.) upto: 143°C.

Fabric speed : 5 -120m/min.

Heating rate : 20°C ~ 130°C/30 min.

Liquor rate : 1:3 ~ 1:12

Power Supply : 380V 50/60 Hz.

Winch Dyeing Machine (lab type)

Hank Dyeing Machine

Hank Dyeing for chemical fiber, polyester staple fiber or cotton etc.

Feature:

The grooves which support the sticks with different distances between sticks

Reversible Impellor to ensure even flow of liquor.

Adjustable flow rate

Automatic temperature control panel

Should have option to inter coupling two or more cabinets of same size for dyeing large batch of hank of same shade

Specification:

No of hanks: 20 Nos

Weight of yarn: Wool: 30, Acrylic: 20

Circular Motor: 1 Kw

Floor: 1, Liquor: 0.4 m2

Capacity :5-25 kg

Diameter of main tank : Φ430

Designed Pressure : 0.44Mpa

Max work Pressure :0.44Mpa

Designed Temperature :98ºC

Max work Temperature :95ºC

Cooling water Temperature :5ºC-10ºC

Power :4.00-7.5KW
