AKRON Abrasion Tester DW9651

Rated 0 out of 5
(be the first to review)

AKRON abrasion tester is suitable to determine the abrasion resistance of vulcanized rubber. The abrasion resistance is determined through measuring the volumetric loss of a rotating specimen abraded against a standard grinding wheel.We provide reasonable price and high quality AKRON abrasion tester. All the testing instruments manufactured by FYI factory are well-known throughout China and more than 50 countries abroad.

AKRON Abrasion Tester DW9651

We provide reasonable price and high quality AKRON abrasion tester. All the testing instruments manufactured by FYI factory are well-known throughout China and more than 50 countries abroad for providing superior value and performance.

AKRON abrasion tester is suitable to determine the abrasion resistance of vulcanized rubber. The abrasion resistance is determined through measuring the volumetric loss of a rotating specimen abraded against a standard grinding wheel. You can set the number of wear revolutions. When the set number of revolutions is completed, the tester can stop automatically.

Follows are features of AKRON abrasion tester:

  • The AKRON abrasion test is equipped with a brush on the left side of the grinding wheel. This brush can rotate synchronously with the grinding wheel, which can remove the debris caused by abrading the specimen;
  • The test load can be obtained by moving the weight to the corresponding indicating scale;
  • The number of wear revolutions can be set freely, and then when the set number of revolutions is completed, the tester can stop automatically.

Application

Application of AKRON Abrasion Tester

AKRON Abrasion Tester is used with a balance to determine the abrasion resistance of rubber products, such as shoe sole, tire, conveyer belt, etc.

AKRON abrasion tester complies with GB/T 1689, BS 903.

If you need more information about AKRON abrasion tester, please contact us.

Standards

Standards of AKRON Abrasion Tester

GB/T 1689 BS 903

Key specification

Key specification of AKRON Abrasion Tester

Grinding wheel DW9651: 36 grit
DW9651-I: 40 grit
Rubber wheel rotating speed (76±2)rpm
Grinding wheel rotating speed (34±1)rpm
Incline angle of specimen 0~35°, adjustable
Counter LCD, 0~999,999
Load DW9651: (26.7±0.2)N
DW9651-I: 1.81kg, 5.43kg
Power supply AC 220V 50Hz
Dimensions 600×450×400mm(L×W×H)
Weight Approx. 60kg
